Product Installation Instructions for Compatible Turn Signal Relay

Compatible Models:

• GSF1200
• GSF1250
  -GSF600
• GSF650
• GSR750
  -GSX-R Series
  -GSX-S750
  -GSX1200
  -GSX1250

Installation Overview:

This turn signal relay is designed to be compatible with a range of motorcycle models, providing an easy and reliable solution for your signaling needs. The installation process is straightforward and can be completed with minimal tools.

Tools Needed:

1. Flathead Screwdriver - To remove any screws securing the relay cover or connections.
2. Phillips Screwdriver - For screws that may be used on the relay housing.
3. Wire Cutters/Strippers - If modifications to wires are necessary.
4. Electrical Tape - To secure any wire connections if splicing is required.
5. Multimeter - To check the electrical connections and ensure proper operation.
6. Socket Wrench Set (optional) - In case bolts need to be removed for access.

Installation Steps:

1. Preparation:

   • Ensure the motorcycle is parked on a stable surface and the ignition is turned off.
   • Disconnect the battery to prevent any electrical issues while working.

2. Access the Relay:

   • Locate the turn signal relay on your motorcycle, usually found under the seat or near the front fairing.
   • Remove the necessary covers or panels using the flathead or Phillips screwdriver.

3. Remove the Old Relay:

   • Carefully disconnect the wires from the old relay. Make a note of where each wire connects for reinstallation.
   • Remove any securing screws or bolts and take the old relay out.

4. Install the New Relay:

   • Position the new relay in place and secure it using the screws or bolts.
   • Reconnect the wiring harness according to the notes taken earlier, ensuring each wire is connected to the correct terminal.

5. Test the Relay:

   • Reconnect the battery and turn on the ignition.
   • Activate the turn signals to ensure they are functioning correctly.
   • Use a multimeter to check the voltage at the relay if signals are not working properly.

6. Finalization:

   • Once confirmed that everything is working, use electrical tape to secure any open connections.
   • Reassemble any covers or panels that were removed during access to the relay.

7. Safety Check:

   • Inspect all connections and ensure there are no loose wires.
   • Take a quick test drive to ensure that the turn signals are functioning as expected.

Conclusion:

This turn signal relay is designed for durability and reliability, ensuring a smooth replacement process that enhances your motorcycle’s signaling system. Following these instructions will make installation easy and efficient. Enjoy safer rides with improved signaling!
