Product Installation Instructions for Ignition Coil Replacement

Compatible Models:
K960, K970 III, 510115603, 544047503, 580380502, 594729602, 580380506

Tools Required:

1. Screwdriver Set (Flathead and Phillips)
2. Wrench or Socket Set (for securing bolts)
3. Pliers (to hold small components)
4. Torque Wrench (optional, for precise tightening)
5. Work Gloves (to protect your hands)
6. Safety Goggles (to protect your eyes)

Installation Steps:

1. Preparation:

   • Ensure the chainsaw is turned off and disconnected from any power source.
   • Wear safety goggles and work gloves for protection.

2. Remove the Chainsaw Cover:

   • Use a screwdriver to remove screws securing the chainsaw cover.
   • Carefully take off the cover to access the ignition coil.

3. Locate the Ignition Coil:

   • Identify the old ignition coil within the chainsaw engine compartment.

4. Detach the Old Ignition Coil:

   • Disconnect any wiring connected to the ignition coil.
   • Use the appropriate wrench or socket to remove any bolts securing the ignition coil.

5. Install the New Ignition Coil:

   • Position the new ignition coil in place.
   • Secure it using the bolts removed earlier, ensuring a snug fit.
   • Reconnect the electrical wiring to the new ignition coil.

6. Reattach the Chainsaw Cover:

   • Replace the cover and secure it with screws using the screwdriver.

7. Test the Chainsaw:

   • Once everything is reassembled, start the chainsaw to test the ignition coil’s performance and ensure everything is functioning properly.

Notes:

• Make sure to dispose of the old ignition coil responsibly.
• If you encounter any difficulties during installation, refer to your chainsaw's manual or seek assistance from a professional.

By following these instructions, you will ensure a successful installation of the Ignition Coil, enhancing the performance of your chainsaw.
