Product Installation Instructions for Magneto Stator Ignition Pulse Coil for GY6 50cc 125cc 150cc

Preparation:

Before starting the installation, ensure you have the following tools ready:

1. Basic Tools:

   • Socket wrench set (10mm and 12mm)
   • Phillips and flathead screwdrivers
     -Torque wrench
     -Pliers
   • Wire cutters/stripper
   • Electrical tape or heat shrink tubing

2. Safety Equipment:

   • Gloves
   • Safety goggles

3. Additional Items:

   • Repair manual specific to your scooter/moped/ATV model (optional but recommended)
     -Clean cloth

Installation Steps:

1. Safety First:

   • Ensure the engine is turned off and cool. Disconnect the battery to avoid any electrical mishaps.

2. Remove the Old Ignition Coil:

   • Locate the existing ignition pulse coil on your vehicle. It is generally situated near the stator.
   • Use the socket wrench to remove any bolts securing the old coil.
   • Unplug the electrical connectors and carefully take out the old coil.

3. Install the New Ignition Coil:

   • Position the new Magneto Stator Ignition Pulse Coil in the same location as the old one.
   • Secure it with the appropriate bolts using a torque wrench if specified in the manual.
   • Connect the electrical connectors, ensuring they are firmly attached.

4. Double Check Connections:

   • Verify that all connections are correct and secure.
   • Use electrical tape or heat shrink tubing to protect any exposed wires.

5. Reconnect the Battery:

   • Reconnect the battery terminals and ensure that they are tightened securely.

6. Test the System:

   • Start the engine to check if it runs smoothly.
   • Observe the engine performance to ensure that the ignition system is working correctly.

7. Final Check:

   • After successful installation and testing, clean up the work area and dispose of any old parts responsibly.

Note: Always consult the vehicle’s repair manual for any model-specific instructions and torque specifications.

By following these steps, you can ensure a successful installation of your new Magneto Stator Ignition Pulse Coil, optimizing your ignition system for improved engine performance.
