Installation Guide for Starter Relay for UTV Models

Tools Required:

• Torx screwdriver (T20)
• Phillips screwdriver
• Wire strippers
  *Needle-nose pliers
• Multimeter (optional)
  *Safety glasses
• Work light (optional)

Important:

• Before starting the installation, make sure to consult your UTV's owner's manual and familiarize yourself with the electrical system.
• Wear protective gear, including safety glasses and a work light, to ensure a safe working environment.
• If you are not comfortable with electrical work or do not have experience with UTVs, consider seeking the help of a professional mechanic.

Step 1: Locate the Old Starter Relay

• Find the old starter relay in your UTV's electrical system. It is usually located near the battery or the starter motor.
• Take note of the wire connections and the mounting screws.

Step 2: Disconnect the Battery

• Disconnect the negative (black) cable from the battery to prevent any accidental starts or electrical shocks.
• Use a wrench or pliers to loosen the nut holding the cable in place.

Step 3: Remove the Old Starter Relay

• Use a Torx screwdriver to remove the screws holding the old starter relay in place.
• Gently pull the relay out of its mounting bracket.

Step 4: Disconnect the Wire Connections

• Use wire strippers to remove any insulation from the wires connected to the old starter relay.
• Use needle-nose pliers to grasp the wires and gently pull them off the relay.
• Take note of the wire colors and connections.

Step 5: Install the New Starter Relay

• Mount the new starter relay in the same location as the old one.
• Use the Torx screwdriver to secure it in place.
• Connect the wire connections to the new relay, matching the colors and connections noted earlier.

Step 6: Reconnect the Battery

• Reconnect the negative (black) cable to the battery.
• Tighten the nut holding the cable in place.

Step 7: Test the Starter Relay

• Use a multimeter to test the voltage at the relay and ensure it is functioning properly.
• Start the UTV and listen for any unusual noises or vibrations.

Tips and Reminders:

• Make sure to dispose of the old starter relay properly.
• Keep track of the wire connections and ensure they are secure.
• If you encounter any issues during installation, consult a professional mechanic for assistance.

By following these steps, you should be able to successfully install the starter relay for your UTV model. If you have any questions or concerns, feel free to ask.
