Product Installation Instructions for Universal Fuel Pump and Filter for ATVs

This universal fuel pump and filter is compatible with various ATV models including Ranger, RZR, and Sportsman series. Follow the steps below for a successful installation.

Tools Required:

1. Socket Wrench Set
2. Screwdriver Set (Flathead and Phillips)
3. Pliers
4. Fuel Line Wrench (if applicable)
   5.Clean Rags
5. Fuel Container
6. Safety Goggles
   8.Gloves

Installation Steps:

1. Preparation:

   • Ensure the ATV is parked on a flat surface with the ignition turned off.
   • Disconnect the battery to prevent any electrical accidents during the installation.

2. Fuel Drain:

   • Use a fuel line wrench (if applicable) to disconnect the fuel lines.
   • Place a fuel container or clean rags underneath to catch any spilled fuel.

3. Remove Old Pump:

   • Locate the old fuel pump and filter assembly.
   • Use the socket wrench to remove any bolts or screws securing the assembly.
   • Carefully detach the old pump and filter from the ATV.

4. Install New Pump:

   • Take the new universal fuel pump and filter out of its packaging.
   • Position the new pump in place and secure it using the original bolts or screws.
   • Ensure that all connections are tight and secure.

5. Reconnect Fuel Lines:

   • Reattach the fuel lines to the new pump, ensuring they are properly fitted to prevent leaks.
   • Double-check connections for security.

6. Reconnect the Battery:

   • Once all components are securely installed, reconnect the ATV’s battery.

7. Test the Installation:

   • Turn the ignition key to cycle the fuel pump and check for any leaks in the fuel lines.
   • Start the engine and let it idle for a few minutes to ensure the pump is functioning correctly.

8. Clean Up:

   • Dispose of any fuel-soaked rags in an appropriate manner.
   • Store all tools safely.

By following these steps, you will successfully install your new universal fuel pump and filter, enhancing the performance and reliability of your ATV. Enjoy your ride!
