Product Installation Instructions for Motorcycle Cylinder Base Gasket Kit

Compatible with:

• 390 Duke (2013-2019)
• 250 Duke (2015-2019)
• 250 RC (2015-2017)

Installation Tools Needed:

1. Wrenches/Sockets:

   • Metric sockets and wrenches (usually 8mm to 13mm)

2. Torque Wrench:

   • For applying correct torque specifications

3. Screwdrivers:

   • Phillips and flathead screwdrivers

4. Pliers:

   • Needle nose pliers may be useful

5. Gasket Scraper/Plastic Scraper:

   • To remove old gasket material without scratching the surfaces

6. Rags/Cleaning Cloths:

   • For cleaning surfaces and wiping up any spills

7. Engine Oil:

   • For lubrication during assembly

8. Safety Equipment:

   • Gloves and eye protection

Step-by-Step Installation Instructions:

1. Preparation:

   • Park your motorcycle on a stable surface.
   • Allow the engine to cool completely.

2. Remove Necessary Components:

   • Begin by removing any parts that obstruct access to the cylinder base, such as the fuel tank, exhaust, or other components.

3. Clean the Surfaces:

   • Use the gasket scraper to gently remove the old gasket material from the cylinder base and other mating surfaces. Ensure these surfaces are clean and free of debris.

4. Apply Engine Oil:

   • Apply a light coat of engine oil to the new gasket. This helps with the sealing process and makes future removal easier.

5. Install the New Gasket:

   • Carefully place the new gasket onto the cylinder base, ensuring proper alignment with all holes and passages.

6. Reassemble Components:

   • Reattach the removed parts in the reverse order of disassembly. Ensure that all bolts are tightened to the manufacturer's specifications using a torque wrench.

7. Final Checks:

   • After reassembly, check all connections and components to ensure everything is secure.

8. Start the Engine:

   • Start the engine and monitor for any leaks.

9. Test Ride:

   • Take a short test ride to ensure that the engine operates smoothly and the installation is successful.

Important Notes:

• Always refer to the motorcycle's service manual for specific torque specifications and assembly guidelines.
• If you are unsure about any part of the installation process, consult a professional mechanic.

Enjoy enhanced performance and a smooth riding experience with your newly installed Cylinder Base Gasket Kit!
