Installation Instructions for Recoil Pull Starter Assembly

Tools Required:

1. Socket Wrench Set - for removing and securing bolts.
2. Screwdriver Set - flathead and Phillips for any screws.
3. Pliers - to grip and manipulate small components.
4. Torque Wrench - to ensure bolts are secured to the manufacturer’s specifications.
5. Clean Cloth - for cleaning surfaces before installation.
6. Safety Goggles - to protect your eyes during installation.

Installation Steps:

1. Preparation:

   • Make sure the ATV/UTV is parked on a flat, stable surface.
   • Disconnect the battery to prevent any electrical issues during installation.

2. Remove the Old Starter Assembly:

   • Use the socket wrench to remove the bolts holding the old recoil pull starter in place.
   • Carefully detach any connected cables or components, taking note of their placement.

3. Clean the Area:

   • Wipe the mounting surface with a clean cloth to remove any debris or old gasket material.

4. Install the New Recoil Pull Starter Assembly:

   • Position the new recoil pull starter in place.
   • Reconnect any cables or components as per the original configuration.

5. Secure the Assembly:

   • Using the socket wrench, secure the bolts tightly to hold the new starter assembly in place.
   • Utilize the torque wrench to ensure bolts are tightened to the recommended specifications.

6. Reconnect the Battery:

   • Once the installation is complete, reconnect the battery terminals.

7. Test the Starter:

   • Pull the recoil starter to ensure smooth operation and confirm that the assembly is functioning correctly.

8. Final Check:

   • Inspect all connections and ensure everything is securely fastened before taking the ATV/UTV on a test run.

Reminder:

Always refer to the vehicle’s owner’s manual for any specific instructions or precautions related to your model.

Enjoy your reliable starts with the new Recoil Pull Starter Assembly!
