Installation Instructions for Ignition Coil Replacement

Compatible Engine Models:

• 269-79430-01
• 269-79430-11
• 269-79430-31
  -EH12 Series
  -EH122 Series
  -EH17 Series
  -EH172 Series
  -EW210TR

Tools Required:

1. Socket Wrench Set - To remove and install bolts and nuts.
2. Screwdriver Set - Both flathead and Phillips head, if any screws are present.
3. Torque Wrench - To ensure proper torque specifications are met during installation.
4. Pliers - Useful for gripping and manipulating wires.
5. Wire Cutters/Strippers - If any wire modification is necessary.
6. Heat-Resistant Gloves - To protect your hands, especially if the engine has been running.
7. Safety Glasses - To protect your eyes during the installation process.
8. Clean Cloth - For cleaning any debris around the installation area.

Installation Steps:

1. Preparation:

   • Ensure the engine is turned off and cool to the touch.
   • Disconnect the battery to avoid any electrical hazards during installation.

2. Remove Old Ignition Coil:

   • Locate the ignition coil, which is typically situated near the spark plugs.
   • Carefully disconnect the electrical connector from the old ignition coil.
   • Use the socket wrench to remove the bolts securing the old ignition coil.
   • Gently pull the old coil out and set it aside.

3. Install New Ignition Coil:

   • Position the new ignition coil into place, ensuring it aligns properly with the mounting holes.
   • Secure the ignition coil using the bolts removed earlier and tighten them with the socket wrench. Use the torque wrench to ensure they are tightened to manufacturer specifications.
   • Reconnect the electrical connector to the new ignition coil.

4. Final Checks:

   • Reconnect the battery.
   • Start the engine to ensure the new ignition coil is functioning correctly.
   • Monitor for any irregular sounds or warning lights to ensure a successful installation.

Note: If you encounter any difficulties during installation, consult the vehicle's service manual or seek assistance from a qualified technician.

Thank you for choosing our ignition coil replacement for your engine models, and we wish you a smooth installation process!
