Product Installation Instructions for Parking Brake Caliper (Replacement for Linhai 260 300 260cc 300cc ATV Quad)

Installation Overview
This parking brake caliper is specifically designed for Linhai 260cc and 300cc ATVs, ensuring a perfect fit and improved performance. Follow these instructions for a hassle-free installation.

Tools Required
Before starting the installation, please ensure you have the following tools ready:

• Socket set (including 10mm and 12mm sockets)
  -Wrench set
• Screwdriver (flathead and Phillips)
  -Torque wrench
• Brake cleaner
• Rags or cloths
• Safety glasses
• Gloves

Installation Steps

1. Preparation
   a. Park your ATV on a level surface and engage the parking brake.
   b. Wear safety glasses and gloves for protection.
   c. Gather all necessary tools and the new parking brake caliper.

2. Remove the Wheel
   a. Use the socket wrench to remove the lug nuts and take off the wheel.
   b. Set the wheel aside in a safe place.

3. Access the Brake Assembly
   a. Locate the existing parking brake caliper.
   b. Use a wrench to remove any bolts securing the caliper to the brake assembly.

4. Remove the Old Caliper
   a. Carefully detach the old caliper from the brake assembly and set it aside.
   b. Clean the area using brake cleaner and a rag to remove any debris or old grease.

5. Install the New Caliper
   a. Position the new parking brake caliper onto the brake assembly.
   b. Secure it using the original bolts or the new ones provided. Tighten them to the manufacturer’s specifications with a torque wrench.

6. Reattach the Wheel
   a. Place the wheel back onto the axle and hand-tighten the slug nuts.
   b. Using the socket wrench, fully tighten the lug nuts in a star pattern for even pressure.

7. Test the Installation
   a. Before starting the ATV, check that everything is securely fastened.
   b. Depress the brake lever to ensure the new caliper is functioning properly.

8. Final Check
   a. Once installed, perform a test by driving the ATV in a safe area to confirm the braking performance.
   b. Recheck the caliper and lug nut tightness after the first short ride.

Enjoy Your Improved ATV Performance!

If you encounter any issues during the installation process or need further assistance, please consult the user manual or a professional mechanic.
