Installation Instructions for Ignition Coil Assembly Module for TJ27 and TJ27E Trimmers and Lawn Mowers

Tools Required:

1. Screwdriver Set

   • Flathead screwdriver
   • Phillips screwdriver

2. Wrench or Socket Set

   • Appropriate sizes to remove engine cover and coil assembly bolts

3. Pliers

   • Needle-nose pliers can be helpful for disconnecting electrical connectors

4. Safety Gear

   • Gloves
   • Safety goggles

Installation Steps:

1. Preparation

   • Ensure the trimmer or lawn mower is turned off and unplugged (if applicable).
   • Put on safety goggles and gloves for protection.

2. Access the Ignition Coil

   • Use the screwdriver and/or wrench to remove any screws or bolts securing the engine cover.
   • Carefully lift off the engine cover to expose the ignition coil.

3. Disconnect the Old Ignition Coil

   • Identify the ignition coil and any electrical connectors attached to it.
   • Use pliers to gently disconnect the wiring from the old coil.

4. Remove the Old Coil

   • Unscrew the ignition coil from its mounting location.
   • Dispose of the old ignition coil responsibly.

5. Install the New Ignition Coil Assembly Module

   • Position the new ignition coil in the same location as the old one.
   • Secure it by screwing it into place.

6. Reconnect the Wiring

   • Attach the electrical connectors to the new ignition coil, ensuring a snug fit.

7. Reassemble the Engine Cover

   • Place the engine cover back on and secure it with screws or bolts.

8. Test the Equipment

   • Start the trimmer or lawn mower to ensure the new ignition coil assembly module is functioning properly.

Conclusion:
With the right tools and following these steps, you can easily install the Ignition Coil Assembly Module for your TJ27 or TJ27E trimmer and lawn mower, enhancing its performance and prolonging its life.
