Replacement Fuel Water Separator Installation Instructions

Compatibility:
This water separator is designed for use with R11T and R11S diesel engines.

Tools Required:

1. Socket Wrench Set - For removing the existing water separator.
2. Screwdriver Set - To assist in removing any securing screws or clips.
3. Pliers - For gripping hoses and clamps.
4. Oil Drain Pan - To catch any fuel or water that may be released during the replacement process.
5. Clean Rags - For cleaning up any spills and for general maintenance.
6. Safety Gloves - To protect your hands while working with fuel systems.
7. Safety Glasses - To protect your eyes from any splashes.

Installation Steps:

1. Preparation:

   • Park the vehicle in a well-ventilated area and ensure the engine is cool.
   • Gather all the necessary tools and materials before starting the installation.

2. Remove the Existing Water Separator:

   • Using the socket wrench, carefully unbolt the old water separator from its mounting position.
   • Use pliers to disconnect any hoses attached to the separator.
   • Be prepared to catch any fuel or water that may spill into the oil drain pan.

3. Install the New Separator:

   • Take your new Replacement Fuel Water Separator and position it where the old one was located.
   • Reconnect the hoses to the matching ports on the new separator, ensuring they are tightly secured.
   • Bolt the new separator in place using the socket wrench.

4. Check for Leaks:

   • After installation, turn on the engine and check for any fuel leaks around the new water separator connections.
   • If you notice any leakage, turn off the engine and tighten the connections as needed.

5. Final Clean-Up:

   • Wipe away any spills with clean rags and dispose of any waste materials properly.
   • Ensure all tools are removed from the work area.

Safety Note:
Always take necessary safety precautions when working with fuel systems. If you are unsure about any step in the replacement process, do not hesitate to consult a professional mechanic.
