Installation Instructions for Replacement Ignition Coil Module

Compatible Models:
-FC55

• FS38
• FS45
  -FS55
• HL45
  -HS45
  -KM55

Tools Required:

1. Screwdriver (Flathead and Phillips)
   2.Wrench or Socket Set
2. Needle-nose Pliers
3. Safety Gloves
4. Safety Goggles

Installation Steps:

1. Preparation:

   • Ensure the machine is turned off and disconnected from any power source.
   • Wear safety gloves and goggles to protect yourself during the installation process.

2. Accessing the Ignition Coil:

   • Remove any covers or panels that are blocking access to the ignition coil module using the appropriate screwdriver.
   • Note the position and connectivity of the old ignition coil for reference.

3. Removing the Old Ignition Coil:

   • Disconnect the wires from the old ignition coil using needle-nose pliers to carefully pull the connectors off.
   • Unscrew the ignition coil from its mounting location using the wrench or socket set.
   • Carefully remove the old ignition coil from the machine.

4. Installing the New Ignition Coil Module:

   • Position the new ignition coil module in place, aligning it as per the original coil’s position.
   • Secure the new coil by tightening the screws with the wrench or socket set.

5. Connecting the Wires:

   • Reconnect the wires to the new ignition coil, ensuring that they are attached to the correct terminals as per your reference from the old coil.

6. Final Assembly:

   • Replace any covers or panels that were removed during the disassembly.
   • Ensure all screws and connections are secure.

7. Testing:

   • Reconnect the machine to the power source and test its functionality.
   • Check that the engine starts smoothly and runs efficiently.

Conclusion:
Congratulations on successfully installing your new Ignition Coil Module! With the improved performance and reliability, your tools will operate at their best.
