Product Installation Instructions for Ignition ECU Box Controller

Tools Required:

1. Screwdriver Set

   • Flathead screwdriver
   • Phillips screwdriver

2. Socket Wrench Set

   • Metric sockets (8mm, 10mm, and 12mm)

3. Pliers

   • Needle-nose pliers for disconnecting wires

4. Wire Strippers/Crimpers

   • For any necessary wire connections

5. Heat Shrink Tubing or Electrical Tape

   • To ensure secure and insulated connections

6. Multimeter

   • For testing electrical connections

7. Safety Gloves
   -To protect your hands during installation

8. Safety Goggles
   -To protect your eyes from debris

Installation Steps:

1. Preparation:

   • Ensure the vehicle is parked on a level surface and the ignition is turned off. Disconnect the battery to avoid any electrical shorts during installation.

2. Access the Old ECU:

   • Locate your existing ECU unit. This is typically found near the engine compartment or under the seat, depending on your CF150 model.

3. Remove the Old ECU:

   • Use the pliers to carefully disconnect any wiring harness connected to the old ECU. Ensure you note the connections for reference during installation. Unscrew it from its mounting using the appropriate socket wrench.

4. Install the New Ignition ECU Box Controller:

   • Position the new ECU in the same location as the old one. Use the screws from the old ECU (or your new screws if applicable) to secure the new unit in place.

5. Reconnect Wiring:

   • Carefully reconnect the wiring harness to the new ECU, following your notes from earlier. Ensure each connection is tight and secure.

6. Double Check Connections:

   • Use the multimeter to test the connections and ensure that everything is functioning correctly.

7. Reconnect the Battery:

   • Once all connections are verified, reconnect the battery.

8. Test the System:

   • Start the vehicle and check for smooth operation. Ensure the engine runs steadily and responds well to throttle input.

9. Wrap Up:

   • If needed, use wire strippers to tidy up any additional wiring, and either heat shrink tubing or electrical tape to insulate any exposed wires.

Safety Note:
Always exercise caution when working with electrical components. If you are unsure about any part of the installation process, consider consulting a professional mechanic.

Enjoy improved engine performance with your new Ignition ECU Box Controller!
