Installation Instructions for Motorcycle Piston Rings Set

Compatible Models:

• NTV Revere 88-93
• NV SW 600 93-94
• VT SW VLX 600 89-07
• XL Transalp 75mm

Tools Required:

1. Socket Wrench Set
2. Torque Wrench
3. Piston Ring Compressor
4. Screwdrivers (Flathead and Phillips)
5. Oil for lubrication (recommended motorcycle engine oil)
   6.Clean Cloths
6. Safety Glasses
   8.Gloves

Installation Steps:

1. Preparation:

   • Ensure the motorcycle is parked on a stable, flat surface.
   • Disconnect the battery to avoid any electrical issues while working.

2. Remove the Engine Cover:

   • Using the appropriate socket wrench, remove the engine cover bolts.
   • Carefully lift the cover off and set it aside.

3. Access the Piston:

   • Remove any necessary components to access the engine's piston. This may include the cylinder head depending on your motorcycle model.

4. Remove Old Piston Rings:

   • Once the piston is accessible, gently use a screwdriver to pry off the old piston rings. Be cautious not to scratch the piston or cylinder walls.

5. Clean the Area:

   • Clean the piston and cylinder walls with a clean cloth to remove any debris or old oil.

6. Install New Piston Rings:

   • Using the piston ring compressor, carefully expand the new piston rings and fit them onto the piston. Ensure that the rings are positioned according to the manufacturer's specifications (check for any markings).

7. Reassemble the Engine:

   • Carefully insert the piston back into the cylinder. Ensure proper alignment.
   • Reinstall the cylinder head and any other components you removed in reverse order.
   • Tighten all bolts to the specified torque using a torque wrench.

8. Final Checks:

   • Inspect all connections and ensure everything is securely fastened.
   • Reconnect the battery.

9. Start the Engine:

   • Start the motorcycle and let it idle for a few minutes. Check for any leaks or unusual noises.

10. Test Ride:

    • Take the motorcycle for a short ride to ensure everything is functioning correctly.

Safety Tips:

• Always wear safety glasses and gloves during installation.
• If you are unsure about any step, consult the motorcycle’s repair manual or seek professional assistance.

Note: This product is designed for specific motorcycle models. Ensure compatibility before installation.
