Installation Instructions for Upgrade Accessories for 1/12 Scale RC Cars

Compatible Models:

-D91
-D96
-MN98

• 99S

Tools Required:

• Small Phillips screwdriver
• Small flathead screwdriver
• Hex wrench set (if necessary)
• Needle-nose pliers
• Clean cloth or work surface mat
• Optional: Loctite or thread lock (for securing screws)

Installation Steps:

1. Preparation:

   • Before starting, ensure your work area is clean and organized.
   • Gather all required tools and the upgrade accessories package.

2. Disassembly:

   • Carefully remove the body of the RC car, if applicable, to access the components.
   • Locate the original steering gearbox and tail beam.
   • Use the Phillips screwdriver to remove the screws securing these components.
   • Gently detach the original parts from the chassis.

3. Install the New Metal Steering Gearbox:

   • Align the new metal steering gearbox with the mounting slots on the chassis.
   • Secure it in place using the screws removed earlier. If desired, apply Loctite to the screws to ensure they remain tight.
   • Use the small flathead screwdriver to ensure the screws are snug but be cautious not to over-tighten.

4. Attach the New Tail Beam:

   • Position the new tail beam where the original was located.
   • Use the appropriate screws from the original assembly to secure the tail beam in place.
   • Again, consider using thread lock to keep the screws secure over time.

5. Reassembly:

   • Once both components are securely installed, carefully place the body back onto the chassis.
   • Ensure all clips or latches are properly attached.

6. Final Checks:

   • Double-check all screws to ensure they are tight.
   • Test the movements of the steering and tail beam to ensure they function smoothly.
   • Make any necessary adjustments to the alignment.

7. Testing:

   • After reassembly, perform a test drive to ensure everything is functioning properly.
   • Monitor the performance and make adjustments as needed.

Congratulations! You have successfully upgraded your 1/12 Scale RC car with the new Metal Steering Gearbox and Tail Beam. Enjoy enhanced performance and durability on your next adventure!
