Installation Instructions for Motorcycle Carburetor for 2-Stroke Racing Models DT125, DT125R, DT180, DT200, DT230, TZR125, RXK

Preparation Before Installation:

Before you begin the installation process, ensure you have the following tools ready:

1. Screwdrivers: Flathead and Phillips head screwdrivers for removing and tightening screws.
2. Wrenches: A set of metric wrenches to disconnect and reconnect the fuel line and carburetor mounting bolts.
3. Socket Set: For easier access to hard-to-reach bolts.
4. Pliers: To help with removing any clips or hoses that may be in place.
5. Fuel Line: In case you need to replace the old fuel line during installation.
6. Cleaning Rags: To wipe away any spilled fuel and keep the workspace clean.
7. Safety Goggles: To protect your eyes from fuel splashes.
8. Gloves: To keep your hands clean and protect them from chemicals.

Installation Steps:

1. Preparation:

   • Make sure the motorcycle is stable and on a flat surface.
   • Disconnect the battery to avoid any electrical issues.

2. Remove Old Carburetor:

   • Use the appropriate screwdriver and wrench to detach the throttle cable and any hoses connected to the old carburetor.
   • Remove the mounting bolts holding the old carburetor in place.
   • Carefully lift the old carburetor away from the engine.

3. Install the New Carburetor:

   • Place the new carburetor in the same position as the old one.
   • Tighten the mounting bolts securely.
   • Reconnect the throttle cable and hoses.

4. Check Fuel Line:

   • Inspect the fuel line for any signs of wear. If it looks damaged, replace it with a new line.
   • Ensure that all connections are tight and leak-free.

5. Final Checks:

   • Double-check all connections and bolts to ensure everything is secured.
   • Reconnect the battery.

6. Test the Motorcycle:

   • Start the engine and allow it to idle.
   • Listen for any unusual sounds and check for fuel leaks.
   • Test ride the motorcycle to evaluate the performance and make any necessary adjustments.

Maintenance Tip:

• Regularly check and clean the carburetor according to the maintenance guidelines provided to keep your motorcycle running at peak performance.

By following these steps, you can successfully install the Motorcycle Carburetor and enhance the performance of your 2-stroke racing model. Enjoy your ride!
