Installation Instructions for Fuel Components (150hp to 425hp Outboard Engines)

Compatible Models:

• 6P3-24563-01-00
• 6P3-WS24A-00-00
• 6P3-WS24A-01-00

Tools Required:
1.Wrench set
2. Screwdriver set (Philips and flat-head)
3. Pliers
4. Fuel line removal tool (if necessary)
5.Clean cloth or rag
6. Safety goggles
7.Gloves

Installation Steps:

1. Safety First:

   • Ensure the outboard engine is turned off and the boat is secure.
   • Put on safety goggles and gloves to protect yourself from fuel and debris.

2. Prepare the Area:

   • Locate the old fuel component on your outboard engine.
   • Use a clean cloth to wipe the surrounding area to prevent dirt from entering the fuel system.

3. Remove the Old Fuel Component:

   • Use pliers or a wrench to disconnect any hoses attached to the old fuel component.
   • Carefully remove any screws or fasteners securing the component in place using the appropriate screwdriver.
   • Gently lift the old fuel component out of the engine.

4. Install the New Fuel Component:

   • Position the new fuel component (e.g., 6P3-24563-01-00, 6P3-WS24A-00-00, or 6P3-WS24A-01-00) in place.
   • Secure it with screws or fasteners that were removed previously.
   • Reconnect the fuel hoses, ensuring a tight fit to prevent leaks.

5. Check Connections:

   • Double-check all connections to ensure they are secure.
   • Make sure no fuel lines are kinked or pinched during installation.

6. Final Inspection:

   • Wipe any spills with a clean cloth.
   • Inspect the area for any signs of leaks or loose connections.

7. Test the Installation:

   • Start the engine and observe the fuel system for any leaks.
   • Allow the engine to run for a few minutes to ensure proper operation and performance.

Conclusion:
Following these installation instructions will help you enhance your outboard engine's fuel system, ensuring optimal performance and efficiency. Should you encounter any issues during installation, please consult a professional technician for assistance.
