Installation Instructions for Carburetor Repair Kit (XR Series 600 Models)

Tools Required:

1. Flathead screwdriver
2. Phillips screwdriver
3. Pliers
4. Adjustable wrench
5. Socket set
6. Torque wrench
   7.Clean rag or cloth
   8.Carburetor cleaner
7. Safety goggles
   10.Gloves

Installation Steps:

1. Preparation:

   • Gather all necessary tools and the Carburetor Repair Kit.
   • Ensure the vehicle is turned off and wait for the engine to cool down completely.

2. Remove the Carburetor:

   • Disconnect the fuel line using pliers.
   • Unscrew and remove the bolts securing the carburetor to the engine using the socket set or adjustable wrench.
   • Carefully lift the carburetor away from the engine.

3. Disassemble the Carburetor:

   • Use the appropriate screwdriver to remove the screws or bolts holding the carburetor cover in place.
   • Once the cover is off, take out the old jets and gaskets.

4. Clean the Carburetor:

   • Use carburetor cleaner to thoroughly clean all parts of the carburetor.
   • Wipe down with a clean rag to remove any debris and dirt.

5. Install New Jets and Gaskets:

   • Refer to the included instructions and select the correct jets and gaskets from the repair kit.
   • Carefully install the new jets and gaskets into the corresponding positions.

6. Reassemble the Carburetor:

   • Replace the carburetor cover and secure it with the screws or bolts.
   • Ensure everything is tightened to the manufacturer's specifications using a torque wrench if necessary.

7. Reattach the Carburetor:

   • Align the carburetor with the engine and secure it with the bolts.
   • Reconnect the fuel line, ensuring there are no leaks.

8. Final Check:

   • Inspect all connections and fittings to ensure everything is tight and secure.
   • Start the engine and check for any leaks or unusual sounds.
   • Take a short test drive to confirm proper operation.

Safety Precautions:

• Always wear safety goggles and gloves when handling tools and cleaning agents.
• Work in a well-ventilated area to avoid inhaling fumes from the cleaning agent.

By following these steps, you can successfully install the Carburetor Repair Kit and enhance the performance of your XR Series 600 model.
