Product Installation Instructions for 84.5mm ATV Piston Kit for 400cc Off-Road Vehicle

Compatibility:

Ensure this piston kit is suitable for your YFM 400 model before proceeding with the installation.

Tools Needed:

To install the 84.5mm ATV Piston Kit, you will need the following tools:

1. Socket Set (including 10mm, 12mm, and 14mm sockets)
2. Torque Wrench
3. Piston Ring Compressor
4. Feeler Gauge
5. Screwdriver Set
6. Pliers
7. Wrench Set (adjustable wrench may be helpful)
8. Crankshaft Locking Tool (if applicable to your model)
9. Rags or Shop Towels (for cleaning purposes)
10. Engine Oil (for lubrication of new parts)
11. Gasket Scraper or Razor Blade (for cleaning old gaskets)
12. Clean Work Area (optional but recommended)

Installation Steps:

1. Preparation:

   • Gather all tools and materials.
   • Ensure you have a clean work area to prevent contamination.

2. Remove the Engine Cover:

   • Use your socket and wrench set to remove the bolts securing the engine cover.
   • Gently lift off the cover and set it aside.

3. Remove the Old Piston:

   • Detach the cylinder head and cylinder by following the manufacturer's guidelines.
   • Carefully remove the old piston and piston rings using the piston ring compressor.

4. Clean the Components:

   • Clean the cylinder bore and engine components thoroughly using rags or shop towels.
   • Ensure no debris or old gasket material remains.

5. Install the New Piston:

   • Apply a thin coat of engine oil to the new piston and piston rings for lubrication.
   • Use the piston ring compressor to fit the new piston into the cylinder smoothly.

6. Reassemble Components:

   • Reattach the cylinder and cylinder head according to the specifications provided in your engine manual.
   • Ensure all bolts are tightened to the correct torque using the torque wrench.

7. Install the Engine Cover:

   • Replace the engine cover and secure it with the appropriate bolts.

8. Test the Installation:

   • Start the engine and listen for any unusual sounds.
   • Check for any leaks around the newly installed parts.

Final Checks:

• Stay attentive to your vehicle's performance after installation.
• Make sure to regularly check oil levels and perform necessary maintenance.

Congratulations on your installation of the 84.5mm ATV Piston Kit! Enjoy enhanced performance in your off-road adventures.
